Link Controls have a wide range of automated door operators to select from. Check out our options and product range

Welcome to Link Controls

We supply a comprehensive range of Industrial and Domestic, Door and Gate operators to the trade. Established in 1990 we are the leading supplier.

We offer an unbeatable level of technical support on the full range of Link products, from the initial enquiry through to installation. Our fully manned support team is always available to assist and advise on everything from motor selection through to your site installation. Great care is taken to provide simple user-friendly instructions with all our products. We also offer training seminars tailored to individual needs. To complement our range of multifunction control panels, we also offer a bespoke service, designed and built in house, providing greater flexibility to meet all our customer requirements.

Expertise within the access control industry is present throughout the company, providing customers with detailed information, competitive prices and the correct product for their specific applications. All this is backed up with full technical literature and assistance from our trained staff. These skills enable us to provide a complete service to our customers, from guidance with the initial enquiry & product selection, to a full design package using the latest computer aided design technology. Whether the order is for a one off or high profile multiple installation we have the ability to give all our customers the same professional care.

Product Spotlight

STA Operator

Product Description

The STA sectional overhead door operator has a 0.55kW, 400V three phase motor. Alternatively, a 0.3kW, 240V single phase version is available.

View Product

Product Overview

  • 1ph (0.3kW, 240V) & 3ph (0.55kW, 400V) Available
  • Available with Hand Crank, Floor Level Hand Chain, High Level Hand Chain or Disengage Mechanism Systems
  • Mechanical or Digital Limits
  • Pre-Wired to a Basic Built on Starter or CS Series Multi-fuction Control Panels.

MDF30-65

Product Description

A direct drive with a torque output of 650Nm which perfectly complements our existing range of direct drive operators.

View Product

Product Overview

  • Integral Safety Gear
  • Floor Level Hand Chain System
  • Safety Interlock Switch for Manual Operation
  • Integral Thermal Protection
  • I.P. 54 Environment Protection
  • Gear Driven Limit Switches
  • Phosphor Bronze Worm Wheel
  • High starting Torque Industrial Duty Motor

CS 310

Product Description

The CS 310 control panel is suitable for both digital and mechanical limits. Limit type, external controls and safety devices are all automatically detected on initial power-up. The CS 310 is supplied in an IP65 enclosure complete with hinged lid, removable cable glands, adjustable mounting feet and three opening options. The CS310 can be used for both 3ph and 1ph operation.

View Product

Product Overview

  • Supply selection between 400v 3ph or 230v 1ph
  • Pluggable terminal connections
  • 4 programmable relay outputs with over 40 functions
  • 2 programmable inputs with over 20 functions
  • Directional traffic light control
  • Rotation direction detection
  • Programmable maintenance counter
  • P65 enclosure with cable glands, the front panel can be opened to either the left, right or vertically

MWD BP-A MWD-RC

Product Description

Radar Detection to Open Your Door

How It Works?

A radar has a distance of 10m, known as it’s sensing field. When an vehicle/person is detected in the sensing field, the radar then sends a signal to the control panel.
An optional remote control allows simple access to setup functions from ground level.

View Product

Product Overview

  • 2 Channel device for vehicle & person detection.
  • Planar microwave technology.
  • Cross traffic suppression
  • Object tracking function.
  • Various adjustment options of relay function.
  • Nine pre-configured comfort profiles for typical door applications.
  • Adjustments with pushbutton at the device or with optional remote control.

CS-250 Mini

Product Description

The CS 250 control panel is suitable for both digital and mechanical limits. Limit type, external controls and safety devices are all automatically detected on initial power-up. The digital limits can be set using the buttons on the PCB, LCD Display programmer* or CS-I pushbutton station*. The CS 250 is supplied in an IP65 enclosure complete with hinged lid, removable cable glands and adjustable mounting feet providing a versatile cable management solution. The CS 250 can be used for 3ph and 1ph operation.

View Product

Product Overview

  • Supply selection between 400v 3ph or 230v 1ph
  • Pluggable terminal connections (screw)
  • 2 programmable relay outputs with over 20 functions
  • Rotation direction detection.
  • Cycle counter
  • Illuminated 3 button pushbutton station
  • P65 hinged enclosure with cable glands
  • On initial power up the control panel automatically detects limit switch type, photocell, safety edge systems

TVRF(C) 100

Product Description

The TVRF / TVRFC Sectional Door Operator is available in 0.37, 0.55 & 0.75 kW power sizes, with 230v Single Phase & 400v Three Phase motor options. These models can be fitted with a High Level Chain System, Disengage Clutch or Floor Level Chain System, which enables the sectional door to be manually opened & closed when required.An Adjustable Slipping Clutch (denoted by a ‘C’) can be provided for additional protection & safety.

View Product

Product Overview

  • Integral Thermal Protection.
  • I.P. 54 Environment Protection
  • Phosphor Bronze Worm Wheel.
  • High starting Torque — Industrial Duty Motor.
  • Industry Standard 1” Shaft.
  • Option of Integral slipping Clutch
  • Choice of Manual Overrides

VST 150

Product Description

The VST 150 control panel has been purpose built for `fast action` industrial doors and gates.

It combines a comprehensive range of control features with an integrated inverter to provide smooth operation of the door.

The panel is housed in a compact steel enclosure, with panel mounted operation buttons and emergency stop.
The diagnostic display informs the customer and installer of the door status

View Product

Product Overview

  • Compact size (400h x 300w x 140d).
  • Smooth inverter operation.
  • LED diagnostic display.
  • Fully programmable inputs.
  • Integrated monitored safety edge.
  • Plug in modules for loop & radio.
  • Panel mounted emergency stop.
  • 230v 1ph 16A supply.
  • Volt free outputs for control / position indication.

CDO 150

Product Description

The CDO - 150 Rolling Door Operator is available with a 1.1kw, 400v Three Phase Brake Motor. These models are fitted with either a Hand Crank, KE Hand Chain System or High Level Hand Chain System which enables the roller shutter door to be manually opened & closed when required

View Product

Product Overview

  • Safety Interlock Switch for Manual Operation
  • Integral Thermal Protection
  • 1” industry standard output shaft
  • IP 54 Environment Protection
  • Gear Driven Limit Switches
  • Phosphor Bronze Worm Wheel
  • High Starting Torque — Industrial Duty Motor
